2026 Ford E-Series Cutaway

In Stock
  • Call for Price MAC HAIK PRICE
  • MAC HAIK PRICE:

Visit our Store

Vehicle Information

VIN: 1FDXE4FN0TDD19868
Stock #: 27501
Model Code: E4F
  • Body Style Chassis
  • Exterior Color Agate Black Metallic
  • Interior Color Black
  • Engine 8 Cyl - 7.3 L
  • Transmission 6-SPEED O/D W/TOW HAUL
  • Fuel Type Gasoline Fuel

Highlighted Features

Feature availability subject to final vehicle configuration. Please reference window sticker for more info.
  • Bluetooth®

Dealer Comments

This New 2026 Ford E-Series Cutaway , is Agate Black Metallic in color with a BLACK interior. Stock Number 27501. You can connect with us by calling (281) 607-4250.


Important Package and Feature Information

Order Code 782A

  • 14,500 Lb Payload Package GVWR
  • Dual High Back Buckets
  • 6-Speed O/D with Tow Haul Transmission
  • AM/FM Stereo with Clock Display and 2 Speakers
  • 16"" X 6"" White Painted Steel Wheels
  • Auxiliary Fuel Port
  • 7.3L V8 Port Fuel Injected Gasoline Engine
  • Vinyl Bucket Seats
  • LT225/75R16E BSW A/S Tires
  • 4.56 Axle Ratio




Exterior and Appearance

  • Steel wheels are economical and provide proven durability.

Safety and Security

  • Forward collision mitigation - Forward thinking. You look away for just a second and suddenly the vehicle in front of you has stopped. That's when the forward collision mitigation system comes to life. When it senses an impending impact, it will activate a combination of features to help prevent or reduce the severity of an accident. Forward collision mitigation is always looking ahead.
  • Forward collision mitigation - Forward thinking. You look away for just a second and suddenly the vehicle in front of you has stopped. That's when the forward collision mitigation system comes to life. When it senses an impending impact, it will activate a combination of features to help prevent or reduce the severity of an accident. Forward collision mitigation is always looking ahead.
  • Rear camera - Watching your back! The rear camera helps you see obstacles and hazards you otherwise couldn't by showing enhanced images of what is behind you. The rear camera is an extra set of eyes that's both convenient and safe.

Technology and Telematics

  • Selective Internet access - a more focused delivery. Selective internet access allows you to tailor the features for your feed, such as sports scores, local news, or current weather. When it comes to getting what you want, selective internet access is a net gain.


ENGINE: 7.3L V8 PORT FUEL INJECTED GASOLINE, TRANSMISSION: 6-SPEED O/D W/TOW HAUL, ORDER CODE 782A, 4.56 AXLE RATIO, TIRES: LT225/75R16E BSW A/S, AGATE BLACK METALLIC, DUAL HIGH BACK BUCKETS, GVWR: 14,500 LB PAYLOAD PACKAGE, AMBULANCE PREP PACKAGE NOT REQUIRED, MANUAL TELESCOPING TRAILER TOW MIRRORS (54E), TRAILER TOWING PACKAGE (CLASS I), LICENSE PLATE BRACKET, NON-CONFIGURABLE DAYTIME RUNNING LAMPS, MAXIMUM FRONT GAWR: 5000 LBS., REAR VIEW CAMERA KIT, POWER EQUIPMENT GROUP
At Mac Haik Ford Pasadena, we're here to Serve you! Our staff is 100% dedicated to customer satisfaction and we understand that you need clear, transparent information throughout the car buying process. With our live market pricing philosophy, we offer the right cars at the right price, and the transparency to back it up!

All Features

  • 4.56 Axle Ratio
  • GVWR: 14,500 lb Payload Package
  • 50 State Emission System
  • Rear-Wheel Drive
  • 78-Amp/Hr 750CCA Maintenance-Free Battery
  • HD 210 Amp Alternator
  • 8980# Maximum Payload
  • HD Gas-Pressurized Shock Absorbers
  • Front And Rear Anti-Roll Bars
  • Hydraulic Power-Assist Steering
  • Single Stainless Steel Exhaust
  • 55 Gal. Fuel Tank
  • Dual Rear Wheels
  • Front Suspension w/Coil Springs
  • Solid Axle Rear Suspension w/Leaf Springs
  • 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs and Hill Hold Control
  • Wheels: 16" x 6" White Painted Steel
  • Tires: LT225/75R16E BSW A/S -inc: Hankook DynaPro HT
  • Black Front Bumper w/Black Rub Strip/Fascia Accent
  • Black Side Windows Trim and Black Front Windshield Trim
  • Black Door Handles
  • Light Tinted Glass
  • Variable Intermittent Wipers
  • Front Windshield -inc: Sun Visor Strip
  • Fully Galvanized Steel Panels
  • Black Grille
  • Auto On/Off Reflector Halogen Daytime Running Lights Preference Setting Headlamps
  • Radio: AM/FM Stereo w/Clock Display & 2 Speakers -inc: Bluetooth® capability and USB input
  • Radio w/Clock
  • 2 Speakers
  • Fixed Antenna
  • Wireless Phone Connectivity
  • Dual High Back Buckets
  • 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
  • 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
  • Manual Tilt/Telescoping Steering Column
  • 4G LTE Embedded Modem Selective Service Internet Access
  • Front Cupholder
  • Manual Air Conditioning
  • Glove Box
  • Front Vinyl Headliner
  • Urethane Gear Shifter Material
  • Vinyl Bucket Seats
  • Regular Dome Lighting
  • Front Black Vinyl Floor Covering
  • Fleet Telematics Modem Tracker System
  • Driver And Passenger Door Bins and 1st Row Underseat Storage
  • Manual 1st Row Windows
  • Driver Information Center
  • Analog Appearance
  • Fixed Front Head Restraints
  • Driver And Front Passenger Armrests
  • 2 12V DC Power Outlets
  • Electronic Stability Control (ESC) Electronic Stability Control (ESC)
  • ABS And Driveline Traction Control
  • Side Impact Beams
  • Automatic Emergency Braking (AEB) Oncoming
  • Collision Mitigation-Front
  • Low Tire Pressure Warning
  • Dual Stage Driver And Passenger Front Airbags
  • Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners

ENGINE: 7.3L V8 PORT FUEL INJECTED GASOLINE

  • (STD)

  • Engine: 7.3L V8 Port Fuel Injected Gasoline
  • 4.56 Axle Ratio
  • GVWR: 14,500 lb Payload Package
  • 50 State Emission System
  • Transmission w/Driver Selectable Mode and Oil Cooler
  • Rear-Wheel Drive
  • 78-Amp/Hr 750CCA Maintenance-Free Battery
  • HD 210 Amp Alternator
  • 8980# Maximum Payload
  • HD gas-pressurized shock absorbers
  • Front And Rear Anti-Roll Bars
  • Hydraulic Power-Assist Steering
  • Single Stainless Steel Exhaust
  • 55 Gal. Fuel Tank
  • Dual Rear Wheels
  • Front Suspension w/Coil Springs
  • Solid Axle Rear Suspension w/Leaf Springs
  • 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs and Hill Hold Control
  • Wheels: 16" x 6" White Painted Steel
  • Black Front Bumper w/Black Rub Strip/Fascia Accent
  • Black Side Windows Trim and Black Front Windshield Trim
  • Black Door Handles
  • Light Tinted Glass
  • Variable Intermittent Wipers
  • Front Windshield -inc: Sun Visor Strip
  • Fully Galvanized Steel Panels
  • Black grille
  • 2 Speakers
  • Fixed Antenna
  • 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
  • 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
  • Manual Tilt/Telescoping Steering Column
  • Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp and Trip Odometer
  • 4G LTE Embedded Modem Selective Service Internet Access
  • Front Cupholder
  • Manual Air Conditioning
  • Glove Box
  • Front vinyl headliner
  • Urethane Gear Shifter Material
  • Partial Floor Console w/Storage and 2 12V DC Power Outlets
  • Regular Dome Lighting
  • Front black vinyl floor covering
  • Fleet Telematics Modem Tracker System
  • Driver And Passenger Door Bins and 1st Row Underseat Storage
  • Manual 1st Row Windows
  • Driver Information Center
  • Analog Appearance
  • Fixed Front Head Restraints
  • Driver And Front Passenger Armrests
  • 2 12V DC Power Outlets
  • Side Impact Beams
  • Automatic Emergency Braking (AEB) Oncoming
  • Collision Mitigation-Front
  • Low Tire Pressure Warning
  • Dual Stage Driver And Passenger Front Airbags
  • Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners
  • Electrical
    • Cold Cranking Amps @ 0° F (Primary): 750
    • Cold Cranking Amps @ 0° F (2nd): 750
    • Maximum Alternator Capacity (amps): 210
  • Weight Information
    • Base Curb Weight (lbs): 5431
    • Gross Axle Wt Rating - Front (lbs): 5000
    • Gross Axle Wt Rating - Rear (lbs): 9600
    • Curb Weight - Front (lbs): 3048
    • Curb Weight - Rear (lbs): 2383
    • Gross Vehicle Weight Rating Cap (lbs): 14500
    • Gross Combined Wt Rating (lbs): 22000
  • Trailering
    • Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
    • Dead Weight Hitch - Max Tongue Wt. (lbs): 500
    • Wt Distributing Hitch - Max Trailer Wt. (lbs): 7500
    • Wt Distributing Hitch - Max Tongue Wt. (lbs): 750
    • Maximum Trailering Capacity (lbs): 7500
  • Suspension
    • Suspension Type - Front: Other
    • Suspension Type - Rear: Leaf
    • Spring Capacity - Front (lbs): 5000
    • Spring Capacity - Rear (lbs): 9600
    • Axle Type - Front: Independent
    • Axle Type - Rear: Rigid Axle
    • Axle Capacity - Front (lbs): 5000
    • Axle Capacity - Rear (lbs): 9600
    • Axle Ratio (:1) - Front: 4.56
    • Axle Ratio (:1) - Rear: 4.56
  • Brakes
    • Brake Type: 4-Wheel Disc
    • Brake ABS System: 4-Wheel
    • Brake ABS System (Second Line): 4-Wheel
    • Disc - Front (Yes or ): Yes
    • Disc - Rear (Yes or ): Yes
    • Front Brake Rotor Diam x Thickness (in): 13.6
    • Rear Brake Rotor Diam x Thickness (in): 13.6
  • Tires
    • Front Tire Order Code: T68
    • Rear Tire Order Code: T68
    • Front Tire Size: LT225/75SR16
    • Rear Tire Size: LT225/75SR16
    • Front Tire Capacity (lbs): 5000
    • Rear Tire Capacity (lbs): 9880
    • Revolutions/Mile @ 45 mph - Front: 709
    • Revolutions/Mile @ 45 mph - Rear: 709
  • Wheels
    • Front Wheel Size (in): 16 X 6
    • Rear Wheel Size (in): 16 X 6
    • Front Wheel Material: Steel
    • Rear Wheel Material: Steel
  • Steering
    • Steering Type: Re-Circulating Ball
    • Turning Diameter - Curb to Curb (ft): 54.8
  • Fuel Tank
    • Fuel Tank Capacity, Approx (gal): 55
  • Exterior Dimensions
    • Wheelbase (in): 158
    • Length, Overall (in): 261.1
    • Width, Max w/o mirrors (in): 79.4
    • Height, Overall (in): 80
    • Overhang, Rear w/o bumper (in): 68.5
    • Cab to Axle (in): 100
    • Cab to End of Frame (in): 168.5
    • Ground to Top of Load Floor (in): 26
  • Interior Dimensions
    • Passenger Capacity: 2
    • Front Head Room (in): 42
    • Front Leg Room (in): 42.1
    • Front Shoulder Room (in): 68.1
    • Front Hip Room (in): 65.6
  • Summary
    • Vehicle Name: Ford E-Series Cutaway
    • Body Style: Chassis
    • Body Code: H

Warranty

  • Basic Warranty: 36 months / 36,000 miles
  • Drivetrain Warranty: 60 months / 60,000 miles
  • Corrosion Warranty: 60 months / Unlimited miles
  • Roadside Assistance Warranty: 60 months / 60,000 miles

May not represent actual vehicle. (Options, colors, trim and body style may vary)
